CC1352r multi protocol dual band wireless solution

        CC1352r is a multi protocol sub-1 GHz and 2.4 GHz dual band wireless MCU. Unlike cc1352p, cc1352r has no power amplifier. The CC1352r device has very low active RF and micro controller (MCU) current, sleep current less than 1 μ A and up to 80Kb ram retention capacity protected by parity, which can provide excellent battery life and support long-term operation in energy collection applications relying on small button batteries.

        The CC1352r device combines a flexible ultra-low power RF transceiver with a powerful 48 MHz arm ? cortex ? - m4f CPU. Low level RF protocol commands stored in ROM or RAM are processed by a dedicated radio controller (arm ? cortex ? - M0), thus ensuring ultra-low power consumption and excellent flexibility. The sensor controller with fast wake-up and ultra-low power consumption 2MHz mode is specially designed for sampling, caching and processing of analog and digital sensor data, so MCU system can maximize sleep time and reduce working power consumption.

        Characteristic:

        Micro controller

1. Powerful 48mhz arm ? cortex ? - m4f processor

2. EEMBC coremark ? score: 148

3.352kb programmable flash memory in the system

4.256kb ROM for protocol and library functions

5.8kb cache SRAM (also available as general RAM)

6.80kb ultra-low leakage SRAM. SRAM is protected by parity to ensure highly reliable operation

        Ultra low power sensor controller with 4KB SRAM

1. Sample, store and process sensor data

2. Independent of system CPU operation

        Peripheral

1.4 32-bit or 8 16 Bit Universal timers

2.12 bit ADC, 200ksps, 8 channels

3. AES 128 bit and 256 bit encrypted accelerometer

        Low power consumption

1. Wide power supply voltage range: 1.8V to 3.8V

2. Active mode Rx: 5.8ma (3.6V, 868mhz), 6.9ma (3.0V, 2.4GHz)

3. Active mode TX (0dbm): 8.0ma (3.6V, 868mhz), 7.1ma (3.0V, 2.4GHz)

4. Active mode TX (+ 14dbm): 24.9ma (868mhz)

5. Sensor controller, low power consumption mode, 2MHz, operating infinite circulating current: 30.8 μ a

6. Sensor controller, active mode, 24MHz, operating infinite circulating current: 808 μ a

        Radio part

1. Dual band RF transceiver lower than 1GHz and 2.4GHz compatible with low power Bluetooth 5 and IEEE 802.15.4 phy and MAC standards

2. Programmable output power up to + 14dbm (lower than 1GHz) and + 5dBm (2.4GHz), with temperature compensation

        Application scenario:

1. Remote sensor application

2. Asset tracking and management

3. Factory automation

4. Wireless medical application

5. Energy collection application

6. Electronic shelf label (ESL)

7. Home and building automation

8. Wireless alarm and security system

9. Motion detector
